Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches), and STP/RSTP/MSTP for network redundancyTACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance network security Easy network management by web browser, CLI, Telnet/serial console, Windows utility, and ABC-01 Supports MXstudio for easy, visualized industrial network management Input/Output Interface

Alarm Contact Channels	Resistive load: 1 A @ 24 VDC
Digital Inputs	+13 to +30 V for state 1-30 to +3 V for state 0 Max. input current: 8 mA

Ethernet Interface

10/100BaseT(X) Ports (RJ45 connector)	EDS-516A Series: 16EDS-516A-MM-SC/MM-ST Series: 14All models support: Auto negotiation speed Full/Half duplex mode Auto MDI/MDI-X connection
100BaseFX Ports (multi-mode SC connector)	EDS-516A-MM-SC Series: 2
100BaseFX Ports (multi-mode ST connector)	EDS-516A-MM-ST Series: 2

Power Parameters

Connection	2 removable 6-contact terminal block(s)
Input Voltage	24VDC, Redundant dual inputs
Operating Voltage	12to45 VDC
Input Current	EDS-516A Series: 0.35 A@24 VDC EDS-516A-MM-SC/MM-ST Series: 0.44 A@24 VDC
Overload Current Protection	Supported
Reverse Polarity Protection	Supported

Physical Characteristics

Housing	Metal
IP Rating	IP30
Dimensions	94x135x142.7 mm (3.7 x5.31 x5.62 in)
Weight	1586g(3.50 lb)
Installation	DIN-rail mounting, Wall mounting (with optional kit)

Environmental Limits

Operating Temperature	Standard Models: 0 to 60°C (32 to 140°F)Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature (package included)	-40 to 85°C (-40 to185°F)
Ambient Relative Humidity	5 to 95% (non-condensing)

MOXA EDS-516A-MM-SC Available Models

Model 1	MOXA EDS-516A
Model 2	MOXA EDS-516A-MM-SC
Model 3	MOXA EDS-516A-MM-ST
Model 4	MOXA EDS-516A-MM-SC-T
Model 5	MOXA EDS-516A-MM-ST-T
Model 6	MOXA EDS-516A-T
