For future-oriented Industry 4.0 inside and outside the electrical cabinet, Weidmuller's flexible remote I/O systems offer automation at it's best. u-remote from Weidmuller forms a reliable and efficient interface between the control and field levels. The I/O system impresses with its simple handling, high degree of flexibility and modularity as well as outstanding performance. The two I/O systems UR20 and UR67 cover all common signals and fieldbus/network protocols in automation technology.

Depth	76 mm
Depth (inches)	2.992 inch
Height	120 mm
Height (inches)	4.724 inch
Width	11.5 mm
Width (inches)	0.453 inch
Mounting dimension - height	128 mm
Net weight	44 g



Version	Remote I/O module, IP20, Digital signals, Input, 16-channel
Order No.	1315200000
Type	UR20-16DI-P
GTIN (EAN)	4050118118346
Qty.	1 pc(s).



Order No.	Type
1315170000	UR20-4DI-P
2009360000	UR20-4DI-P-3W
1315180000	UR20-8DI-P-2W
1394400000	UR20-8DI-P-3W
1315200000	UR20-16DI-P
1315210000	UR20-16DI-P-PLC-INT
1315190000	UR20-8DI-P-3W-HD
2457240000	UR20-8DI-ISO-2W
1460140000	UR20-2DI-P-TS
1460150000	UR20-4DI-P-TS
1315350000	UR20-4DI-N
1315370000	UR20-8DI-N-3W
1315390000	UR20-16DI-N
1315400000	UR20-16DI-N-PLC-INT
1550070000	UR20-4DI-2W-230V-AC

  Digital input modules P- or N-switching; Reverse polarity protection, up to 3-wire +FE Digital input modules from Weidmuller are available in different versions and are used primarily to receive binary control signals from sensors, transmitters, switches or proximity switches. Thanks to their flexible design, they will satisfy your need for well co-ordinated project planning with reserve potential. All modules are available with 4, 8 or 16 inputs and comply fully with IEC 61131-2. The digital input modules are available as P- or N-switching variant. The digital inputs are for Type 1 and Type 3 sensors in accordance with the standard. With a maximum input frequency of up to 1 kHz, they are used in many different applications. The variant for PLC interface units enables rapid cabling to the proven Weidmuller interface sub-assemblies using system cables. This ensures rapid incorporation into your overall system. Two modules with a timestamp function are able to capture binary signals and to provide a timestamp in 1 μs resolution. Further solutions are possible with the module UR20-4DI-2W-230V-AC which works with accurant current up to 230V as an input signal. The module electronics supply the connected sensors from the input current path (UIN).
