Numerous national and international approvals and qualifications in accordance with a variety of application standards make the W-series a universal connection solution, especially in harsh conditions. The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution. Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059. The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Weidmulle‘s W series terminal blocks save space， Small “W-Compact” size saves space in the panel. Two conductors can be connected for each contact point.



Version	Test-disconnect terminal, Screw connection, 6 mm², 630 V, 41 A, sliding, dark beige
Order No.	1934810000
Type	WTL 6/1 EN
GTIN (EAN)	4032248592166
Qty.	50 pc(s).



Depth	47.5 mm
Depth (inches)	1.87 inch
Depth including DIN rail	48.5 mm
Height	68.5 mm
Height (inches)	2.697 inch
Width	7.9 mm
Width (inches)	0.311 inch
Net weight	19.78 g



Order No.: 2863880000	Type: WTL 6 STB
Order No.: 2863890000	Type: WTL 6 STB BL
Order No.: 2863910000	Type: WTL 6 STB GR
Order No.: 2863900000	Type: WTL 6 STB SW
Order No.: 1016700000	Type: WTL 6/1
Order No.:1934820000	Type: WTL 6/1 EN STB
